58
CONNECTORS & RECEPTACLES
IEEE 1394 FIREWIRE CONNECTORS PHONE: 773 792-2700
* Please visit the product pages on our website for the most up-to-date product information
IEEE 1394 FIREWIRE CONNECTORS
1394RAPC
Switchcraft introduces both right angle PC and surface
mount versions of IEEE 1394 Firewire connectors. The
Firewire connectors are becoming another connector
standard used in the upcoming multimedia/computer
market. The connectors meet IEEE 1394R-4006N Series
standards.
FEATURES AND BENEFITS
? Shielded housings to reduce EMI/RFI emissions
? Mounting posts add stability for wave soldering
? Low profile requires less space
APPLICATIONS
? Multimedia
? Video
? Personal Computers
? Computer Peripherals
SPECIFICATIONS
GENERAL
Voltage Rating: 40 VAC
Current Rating: 1.5A
Contact Resistance: 30m Ohms Max.
Temperature Rating: -55°C to +105°C
Insertion Force: 6.0 lbs. Max.
Withdrawal Force: 4.4 lbs. Min.
Lifecycles: 1,500 Min.
1394SMT
Part Number
1394RAPC
1394SMT
Description
IEEE 1394 RAPC
IEEE 1394 SMT
Note: Special order only, contact factory for details.
DIMENSIONS ARE FOR REFERENCE ONLY
www.switchcraft.com
Inch
(mm)
? Registered trademark of Switchcraft, Inc.
Note: Contact your Switchcraft Representative for price and delivery
